Arc audio 1000.6 dsp

DSP Equipped No - Optional (IPS8.8)

Stereo @ 4 Ohms 6 x 175 Watts

Stereo @ 2 Ohms 6 x 175 Watts

Stereo @ 1 Ohms N/A

Bridgeable Speaker Outputs Yes

Bridged @ 4 Ohms 3 x 350 Watts

Bridged @ 2 Ohms N/A

Other Channels @ 4 Ohms N/A

Other Channels @ 2 Ohms N/A

Other Channels @ 1 Ohms N/A

Output Load Switch Yes

Output Type Class-D

Fuse Rating 3 x 30 Amp

Idle Current TBD

Amplifier Operating Voltage Range 8.0V - 17.1V

Adjustable Class-D Switching Frequency Yes

Built-in Fan Cooled Yes - Variable Speed Ball Bearing Fan

Input Channels (Analog) 2

Input Channel Selection N/A

Input Channels (Analog Type) Balanced (RCA or Speaker Level)

Input Sensitivity (Analog) 200mV - 8V

Input Impedance (Analog) 10k Ohms

Input Gain Type Analog Control (1 control p/pair channels, chnnels L/R)

Audio Output (RCA) 2

Amplifier Slave In/Out (RCA) N/A

Frequency Response 10Hz - 30kHz

S/N Ratio @ 1 Watt TBD

S/N Ratio @ Full Power TBD

S/N Digital N/A

DSP Operating Voltage N/A

Auto-Sense Turn-on Yes - Signal & DC (BTL) (Uses Ch 1/2 Analog Inputs Only)

User Defined Presets N/A

Preset Control Without PC Or Controller N/A

Compatible External Control (Optional) N/A

Dual External Control Use (Optional) N/A

AXP Wifi Control Adapter Card N/A

DSP Integrated On/Off Timing Control N/A

External Amplifier Remote "Turn-on Output" On/Off Timing Control N/A

iDatalink Maestro Amplifier Replacement Interface Capable N/A

iDatalink Maestro Compatibility List N/A

Multi-Processor System Expandability N/A

USB Connection Type USB-Micro

Tuning Software Interface N/A

DNA Tuning Software Interface Download N/A

DNA Software Tuning Features N/A

Auto-Sense Turn-on Yes (DC Detect & Signal Sense)

Crossover Type Ch 1/2 LP, HP, Full

Crossover Range Ch 1/2 50Hz - 500Hz

Crossover Type Ch 3/4 N/A

Crossover Range Ch 3/4 N/A

Crossover Type Ch 5/6 N/A

Crossover Range Ch 5/6 N/A

Bandpass Crossovers N/A

Crossover/Front-end "Bypass" N/A

Bass Boost Yes - 0-12dB @ 45Hz

Onboard Diagnostics Yes - Protection: Thermal, Under/Over Voltage, Short, DC & More

Clip Warning Lights No

Compatible External Level Control Yes

Dual External Control Use (Optional) N/A

Remote Turn-on Pass Through Yes

Cosmetic Trim Level N/A

Dimensions 15 3/8"(L) x 6 3/8"(W) x 2 1/4"(H)
